5l Egg Liquid Aseptic Bag Filler Machine , Mayonnaise Bag In Drum Aseptic Filling Equipment
Aseptic Filler:
Designed to fill fluids, concentrates and particulate products, our aseptic fillers provide: “steam only” sterilization of the filler head(s), complete sanitation by an automatic clean-in-place system and without chemicals or sterile gasses used. High production speed achieved by a newly designed head system. The aseptic filling chamber which can be opened without losing asepticity. Versatility and reliability are improved by meeting various packing standards with different products and the use of a fully PLC controlled self-diagnostic operational mode.
FEATURES & BENEFITS
• Lower labor costs
• Ideal to fill different volume bags
• Processes products with pH <4.5
• Drums are set up in line on a conveyor/operation table
• Single head and double head structure available
DETAILS
• Operates with 10-220 liters (5-60 gallons) aseptic bags
• Filling weight accuracy or by flowmeter to control mass
SERVICE & SUPPORT
• Training
• On-site Service & Maintenance
• Technology guide
PARTS & UPGRADES
• Sparts Parts
• Matched aseptic bag
• Upgrades
Technical Parameter:
| Aseptic Filler | ||
| Type | YGT-AF-1 | YGT-AF-2 |
| Capacity | 1-3000l/h | 4-6000l/h |
| Power | 0.55kw | 1.1kw |
| Steam consumption | 30-40kgs/h | 60-80kgs/h |
| Size | 2200x1000x2300mm | 4000x1000x2500mm |
| Material | SUS304/SUS316L | |
